Factory Amplified or Non-Factory Amplified?  See "Package Options" tab below for assistance with identifying your Jeep.

• Installation Note: Note: Jeeps without the factory amplified system will receive pods without the small tweeter in the pod.  Only the factory amplified jeeps pods will include the small tweeter.  Be sure to select the correct pods to avoid damage to your radio. See the "Package Options" tab below for identification.
• Compatibility:  This system is compatible with factory amplified systems!

TESTED AND APPROVED BY TRAIL SEVEN: The Alpine Speaker Bundles have been installed and tested on our Trail Seven Jeep and we're pleased to put our stamp of approval on these speakers!

• Overview
• Package Options

• Product Highlights
• Ask A Question

• Overview

  Regardless if you have the factory amplified system (Premium), or the factory non-amplified system (Standard), we have a bundle that is right for you and your jeep!  You'll find the explanation of factory amplified systems (Premium) and factory non-amplified systems (Standard) on the "Package Options" tab above.

  All of our bundles are pre-wired and completely assembled prior to shipping from our Frederick, Maryland shop. When you get your bundle, it's all ready to drop in your Jeep! Here's what you can expect to be in your Alpine Speaker Plug & Play Bundle from Trail Seven with a choice of no knee panel speakers, or full range 6.5" component speakers.

  OPTIMIZED FOR THE JEEP

  These 6.5-inch speakers in the SPV-65X-WRA are tuned specifically for the Jeep's in-cabin environment and fit into the factory speaker locations for an easy update that will impress your ears.


  CLEAN, ACCURATE AUDIO

  Crafted with a unique combination of Poly Propylene, Glass Fiber, and Mica Cone materials, the S2-S65 is designed for lightweight construction, high output, and low distortion, giving you a clean and accurate audio experience.

  HAMR SURROUND

  Alpine-Exclusive High Amplitude Multi-Roll (HAMR) surround technology is integrated into the speaker design which allows for maximum cone movement, delivering powerful and accurate bass notes.

  • Sound Bar- 6.5” Coaxial Speakers with 1” Tweeters
  • Knee Panel Speakers- 6.5" woofers pre-loaded with poly-fil into knee panel pods
  • Dash Speakers- 1" Tweeters pre-assembled with crossovers and mounting brackets
  • Includes vehicle specific speaker connectors

  • MB Quart knee pod (in factory amplified systems only)
  • Select Increments® JL/ JT sound bar speaker pods, pre-drilled
  • All required speaker adapters will be pre-sized for ease of installation
  • Plug & play speaker connectors will be pre-wired prior to shipping for ease of installation
  • Plug and Play bundles will have all speaker pods drilled and set with speakers prior to shipping
  • Follow our installation videos above to complete your speaker upgrade!
  • See below for even more details!

  Interested in our bundle for your JL or JT Jeep but have a question first? Simply complete the form below and we'll get back to you promptly!




  Ask A Question

• Is your Jeep Factory Amplified?

  Factory Amplified:

  The easiest way to determine if your jeep is factory amplified or not, is to identify the factory subwoofer which is always paired up with the amplified package.  See pics for easy identification for the '18- '23 Wrangler JL and the '20- '23 Gladiator JT.  If your Jeep is equipped with the below, then you will select Factory Amplified from the drop down menu.

  See the Installation Guide for further clarification and installation procedures.







  Ask A Question

• Product Highlights

  Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status system, the Next-Generation Alpine S-Series Speakers are now Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This new benchmark in sound quality elevates the Next-Gen S-Series Speakers resulting in a more accurate and natural sound at an entry-level price point.

  SPV-65X-WRA

  The SPV-65X-WRA is a complete speaker system upgrade that is Alpine engineered for the Jeep

  • 6.5-inch speakers which can be installed as a component or coaxial system, using the included adapters

  • CTA-2031 Power Rating: 75W RMS, 225W Peak

  • Nominal impedance 4 Ohm

  • Frequency response 65-22kHz

  • 1” Teteron dome tweeter

  • Steel frame with factory speaker mounting tabs

  • Weather resistant: IP55

  • Includes vehicle specific speaker connectors
  • Max RMS Power Capacity: 75W
  • Peak Power Capacity: 225W

  S2-S65

  Next-Generation S-Series 6.5" Coaxial 2-Way Speaker Set

  • Hi-Res Audio Certified (Up to 40kHz)

  • Poly Propylene, Glass Fiber, and Mica Cone Material
  • Lightweight Design with High Output and Low Distortion
  • High-Amplitude Multi-Roll (H.A.M.R.) Surround 
  • Integrated 1” Tweeters (Coaxial)
  • Woofer Size: 6.5”
  • Tweeter Size: 1” (Coaxial)
  • Power Handling: 80W RMS / 240W Peak
  • Frequency Response: 70Hz - 40kHz (Hi-Res)
  • Sensitivity: 88dB

  SPV-10TW-WRA

  Weather-Resistant 1” Component Tweeters for 2007 – Up Jeep® Wrangler and Jeep® Gladiator

  • Weather-Resistant 1” Component Tweeters
  • Teteron Dome Tweeter
  • Plug-and-Play Installation: Utilizes Factory Locations and Vehicle-specific Harnesses/Connectors
  • Crossover with two tweeter level output options: 0dB (flat) for “Tombstone” on-axis applications and +3dB for in-dash off-axis applications
  • Compatible with 2007 – Up Jeep® Wrangler and Jeep® Gladiator
  • Power Handling: 75W RMS / 225W Peak
  • Frequency Response: 2kHz - 22kHz
  • Nominal Impedance: 4Ω
  • Diaphragm: 1”
